Video & Audio

• Image Sensor : 1/2.8" CMOS  Sensor
• Resolution : 3840x2160(8Megapixels) @25fps
• Lens : f=2.7-13.5mm Max.F=1.6
• Zoom : 5X optical zoom
• Video Compression : H.265/H.264
• Field of View : Horizontal: 108.6°- 32° / Vertical: 56.2°- 18° / Diagonal: 133°- 36.7°
• Day & Night : IR-cut filter with auto-switching
• Infrared Night Vision : Up to 30meters(100ft); LED: 4pcs/4W/850nm
• Color Night Vision : With spotlights:4pcs LEDs/0~4W adjustable/4000k/600 lumens
• Frame Rate : Main Stream: 2fps - 30fps(default: 30fps) / Sub Stream: 4fps - 15fps(default: 10fps)
• Code Rate : Main Stream: 2048Kbps -9216Kbps(default:7168Kbps) / Sub Stream: 64Kbps - 512Kbps(default: 512Kbps)
• Audio : Two-way audio

AI

• AI Video Search : Yes
• Person & Object Detection : Person Detection, Vehicle Detection, Animal Detection, Motion Detection
• Smart Event Detection : Object Removal Detection(Beta) , Forgotten Object Detection(Beta)
• Perimeter Protection : Line Crossing Alert, Zone Intrusion Alert, Zone Loitering Alert
• Smart Detection Setting : Person object size / Person sensitivity / Person alarm delay / Vehicle object size / Vehicle sensitivity / Vehicle alarm delay; Animal object size / Animal sensitivity / Animal alarm delay / Detection zone

Power

• DC Power : DC 12.0V⎓2A,  <15W

Interface

• Ethernet Port : One  10M/100Mbps  RJ45
• Storage : MicroSD card slot (Max. 512GB) Reolink NVR, ftp
• Reset Button : YES
• Alarm In/Out : 1 input, 1 output (input:12V/1A; output:12V/500mA)
• Audio In/Out : Built-in Microphone&Speaker

Software Features

• Browser Supported : Edge, Chrome, Firefox, Safari
• OS Supported : PC: Windows, Mac OS; Smartphone: iOS, Android
• Protocols & Standards : HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
• Max.User Access : Max. 20 users (1 admin & 19 user);  Max. 12 simultaneous streams (2 main & 10 sub streams)

Other Features​

• Recording Modes :  Motion-triggered recording (default); Scheduled recording, 24/7 recording
• Smart Home Compatibility : Google Assistant
• AI ISP : Yes
• HDR : Yes
• Time Lapse  :Yes

Working Environment

• Operating Temperature: -30°C~+55°C
• Operating Humidity: 10% ~ 90%
• Weatherproof : IP67

Mechanical

• Dimensions : 76x74x220mm
• Weight (Without Accessories) : 776g
