System

• Main Processor : Industrial-grade processor
• Operating System : Embedded Linux
• Operating Interface : Web, Local GUI

AI

• AI by Recorder : Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; AcuPick
• AI by Camera : Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map; PPE detection; smart object detection; smart sound detection; AcuPick
• AcuPick Performance of AI by Recorder (1080P) (Number of Channels) : 4 channels
• AcuPick Performance of AI by Camera (1080P) (Number of Channels) : Max. 8-channel, 1 combined event per channel/s

Perimeter Protection

• Perimeter Performance AI by Recorder (Number of Channels) : 8 channels, 10 IVS rules for each channel
• Perimeter Performance of AI by Camera (Number of Channels) : All channels (8 targets/s)

Face Detection

• Face Attributes : Gender; age group; glasses; expressions; face mask; beard
• Face Detection Performance of AI by Recorder (Number of Channels)b : 4 channels (up to 12 face images/s each channel)
• Face Detection Performance of AI by Camera (Number of Channels) : All channels (8 targets/s)

Face Recognition

• Face Database Capacity : Up to 20 face databases with 30,000 images, with a total capacity of 3.75 GB. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
• Face Recognition Performance of AI by Recorder (Number of Channels) : 1. 8-channel FD (by camera) + FR (by recorder), image stream: 8 face images/s / 2. 4-channe FD (by recorder) + FR (by recorder), video stream: 24 face images/s
• Face Recognition Performance of AI by Camera (Number of Channels) : All channels (8 targets/s)

SMD

• SMD Plus by Recorder : 8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
• SMD by Camera : All channels (16 targets/s)

Video Metadata

• Metadata Performance of AI by Recorder (Number of Channels) : 4 channels, 22 attributes extraction.
• Metadata Performance of AI by Camera (Number of Channels) : All channels (8 targets/s)
• People Attributes : Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella
• Motor Vehicle Attributes : License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location
• Non-motor Vehicle Attributes : Vehicle model, vehicle color, number of persons, helmet

Vehicle License Plate Comparison

• ANPR by Camera (Number of Channels) : All channels (8 targets/s)
• License Plate Database Capacity : 1. Create up to 20,000 plate numbers. / 2. Blocklist and allowlist

Audio and Video

• Access Channel : 8 channels
• Network Bandwidth : AI disabled: 448 Mbps incoming, 448 Mbps recording and 448 Mbps outgoing / AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
• Resolution : 32 MP;24 MP;16 MP;12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p;960p;D1;CIF;QCIF
• Decoding Capability : AI disabled: 2-channel 32 MP@25 fps; 2-channel 24 MP@25 fps; 5-channel 16 MP@30 fps; 6-channel 12 MP@30 fps / AI enabled: 1-channel 32 MP@25 fps; 2-channel 24 MP@25 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps
• Video Output : 1 VGA, 1 HDMI / VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 / HDMI: 7680×4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 / Heterogeneous video source output for HDMI and VGA
• Multi-screen Display : Main Screen: 1/4/8/9 / Sub Screen: 1/4/8/9
• Third-party Camera Access : ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha

Compression Standard

• Video Compression : Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
• Audio Compression : G.711a; G.711u; PCM; G726
• Network
• Network Protocol : HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; FTP; SFTP; DHCP; DNS; SMTP; UPnP; DDNS; SNMP; Alarm Server; IP Search (Supports IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI
• Mobile Phone Access : iOS; Android
• Interoperability : ONVIF 24.12(Profile T; Profile S; Profile G; Profile M); CGI; SDK
• Browser : Chrome; IE; Safari; Edge; Firefox

Recording Playback

• Multi-channel Playback : Up to 8 channels
• Record Mode : General, motion detection; intelligent; alarm; POS
• Backup Method : USB device and network
• Playback Mode : Instant playback, general playback, event playback, target Video, video clip, tag playback, smart playback (face and motion detection)

Storage

• Disk Group : Yes

Alarm

• General Alarm : Motion detection; local alarm; alarm box; camera external alarm; network alarm; scene changing; PIR alarm; thermal alarm
• Anomaly Alarm : Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan; cybersecurity exception
• Intelligent Alarm : Face detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map; PPE detection; smart object detection; smart sound detection
• Alarm Linkage : Record; snapshot (panoramic); local alarm output; IPC external alarm output; audio; buzzer; log, preset; email

Port

• Audio Input : 1-channel RCA
• Audio Output : 1-channel RCA
• Alarm Input : 4 channels
• Alarm Output : 2 channels
• Disk Interface : 2 SATA ports, each disk can contain up to 20TB. This limit varies depending on the environment temperature.
• RS-232 : 1
• RS-485 : 1
• USB : 2 (1 front USB 2.0 port, 1 rear USB 3.0 port)
• HDMI : 1
• VGA : 1
• Network Port : 1 (10/100/1000 Mbps Ethernet port, RJ-45)

General

• Power Supply : 12 VDC, 4 A
• Power Consumption : Total output of NVR is ≤ 10 W (without HDD)
• Net Weight : 1.55 kg (3.42 lb)
• Gross Weight : 2.77 kg (6.11 lb)
• Product Dimensions : 375.0 mm × 284.8 mm × 56.0 mm (14.76" × 11.21" × 2.20") (W × D × H)
• Packaging Dimensions : 427.0 mm × 137.0 mm × 356.0 mm (16.81" × 5.39" × 14.02") (W × D × H)
• Operating Temperature : –10 °C to +55 °C (+14 °F to +131 °F)
• Storage Temperature : –20 °C to +60 °C (–4 °F to +140 °F)
• Operating Humidity : 10%–93% (RH), non-condensing
• Certifications : CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 / CE-LVD: EN 62368-1:2014
