ASUS Motherboard LGA1700 mATX DDR5 PRO B760M-C-CSM

Order Code: 29242

Order Code: 29242

Stock Level: Only 4 pieces left

Price €159.₀₀

Promo Price(Online only) €155.₀₀

Micro-ATX B760 business motherboard with enhanced security, reliability and manageability and serviceability.

Intel® LGA 1700 socket: Ready for 14th, 13th and 12th Gen Intel® processors
ASUS CSM program: A stable motherboard supply, end-of-life notifications, and IT software for business motherboards
ASUS Control Center Express: Integrated IT monitoring and management software that simplifies enterprise-level system administration
Enhanced system security: A self-recovering BIOS
Consistent and reliable performance: High-quality components and rigorous testing to help ensure durability in harsh environments
Efficient management and customization: An event log and commercial BIOS kit to enable easy maintenance
Better serviceability: Q-LED Core diagnostic display and COM debug header to facilitate building and support processes
Ultrafast connectivity: PCIe 4.0, DDR5, front USB 3.2 Gen 1 Type-C®

Performance Core

CPU (Processor): Supports Intel Core 14th, 13th, and 12th Generation processors in the LGA 1700 socket.
Memory (RAM): Uses the newest DDR5 RAM.
- It has 4 slots and supports a massive 192GB total capacity.
- It handles very fast speeds (up to 6200 MHz with overclocking).
Chipset: Uses the Intel B760 chipset, which provides good features and connectivity.

Storage and Expansion

Fast Storage: Includes 2 slots for super-fast PCIe 4.0 M.2 SSDs. These are the fastest drives available, making your PC boot and load programs quickly.
Standard Storage: Has 4 SATA ports for traditional hard drives (HDDs) or slower SSDs.
Graphics Card Slot: One main PCIe 4.0 x16 slot for a modern graphics card.
Other Slots: Two smaller PCIe 3.0 x1 slots for expansion cards (like sound or capture cards).

Connectivity (Ports)

Video: It supports connecting to three different types of monitors: 2 DisplayPorts, 1 HDMI port, and 1 older VGA port (helpful for business/legacy setups).
Internet: A reliable Intel 1 Gigabit Ethernet port. (Note: Wi-Fi requires a separate card).
USB Ports:
- Rear: 2 fast USB 3.2 ports and 2 standard USB 2.0 ports.
- Front: Headers to connect additional ports on the PC case, including a connector for a modern USB Type-C port.
Legacy Connections: Includes ports for PS/2 keyboard/mouse and internal headers for COM and LPT ports, which are essential for some specialized business equipment.
